Nema23 Brushless 24V 200RPM BLDC Gear Motor 57BL03B-040AG15 For Vending Machine

The planetary gearbox motor is used for the automatic vending machine, the function is moving the robotic arms and pick up the goods.

57BL03B-040AG15 used a powder metallurgy gearbox, so the motor has a long life span and low noise. Which can reach 40dB when operating.

Electrical Specification:

		Model
Motor Part		57BL03B-040AG15
Number Of Phases	Phase	3
Number Of Poles	Poles	4
Line To Line Resistance	OHMS	0.8
Nominal Voltage	VDC	24
Rated Speed	Rpm	3000±200
Rated Torque	N.m	0.18
Torque Constant	N.m/A	0.057
Back EMF constant	V/kRPM	5.9
Weight	Kg	0.56
MOTOR SPECIFICATIONS WITH PLANETARY GEAR
Rated Torque	N.m	1.9
Rated Speed	Rpm	200±10%
Body Length	mm	124
Power	W	40
RATIO		15:1

*Products can be customized by special request.

The electrical data of 57BL03B series is as follows:

Motor Part number 57BL03B-series	Voltage	Speed	Reduction ratio	Gearbox Rated tolerance torque(Nm)	Gearbox Max momentary tolerance torque	Poles	Phase
Motor Part number 57BL03B-series	Voltage	Speed	Reduction ratio	Gearbox Rated tolerance torque(Nm)	Gearbox Max momentary tolerance torque	Poles	Phase
	24V	750RPM	4	2	6	4	3
		500RPM	6	2	6
57BL03B-040AG15		200RPM	15	8	25
		167RPM	18	8	25
		115RPM	26	8	25
		63RPM	48	16	50
		45RPM	66	16	50

Product Application

Automatic Vending Machine gearbox motor

Wiring Diagram

ELECTRICAL CONNECTION TABLE
FUNCTION	COLOR
+5V	RED	UL1007 26AWG
HALL A	YELLOW
HALL B	GREEN
HALL C	BLUE
GND	BLACK
PHASE A	YELLOW	UL1015 20AWG
PHASE B	GREEN
PHASE C	BLUE

Mechanical Dimension

You can choose different gearbox from:

Out diameter 56mm Powder metallurgy

Housing material	Bearing at output	Radial load(10mm from flange)N	Shaft axial load(N)	Shaft press-fit force max(N)	Radial play of shaft(mm)	Thrust play of shaft(mm)	Backlash at no-load (°)
Powder metallurgy	sleeve bearings	≤450	≤200	≤1000	≤0.03	≤0.1	≤1.5

Reduction ratio	Rated tolerance torque (Nm)	Max momentary tolerance torque (Nm)	Efficiency%	Length L (mm)	Weight(g)	Number of gear trains
1/4	2.0	6.0	81%	41.3	491	1
1/6
1/15	8.0	25	72%	59.6	700	2
1/18
1/26
1/47	16	50	72%	59.6	700	2
1/66

Mechanical Dimension
