57mm Gearbox Stepper Motor Nema 34 1.2 Degree 4 Kg Cm

Ask Lasest Price
Brand Name :	HeTai
Model Number :	57BYGH350
Certification :	CE ROHS ISO
Price :	USD
Payment Terms :	L/C, D/P, T/T, Western Union, MoneyGram
Supply Ability :	10000 PCS/MONTH
Delivery Time :	25 DAYS

Add to Cart

Product Details
Company Profile

57mm Gearbox Stepper Motor Nema 34 1.2 Degree 4 Kg Cm

57BYGH350 Nema 34 1.2 degrees step angle stepper motor with electric reduction gearbox low noise

The 1.2 degrees 57mm stepper motor can match with 42mm, 56mm Powder metallurgy gearbox and 52mm Zinc alloy gearbox. The rated tolerance torque is 16 Nm, and max momentary tolerance torque of 56mm gearbox, which can reach the highest torque of all. The Radial load(10mm from flange) of the 56 mm gearbox is ≤ 450N, and the Shaft axial load is ≤ 200N.

MOTOR PART Electrical Specification

MODEL	STEP ANGLE (°/STEP)	LEAD WIRE (NO.)	VOLTAGE (V)	CURRENT (A/PHASE)	RESISTANCE (Ω/PHASE)	INDUCTANCE (MH/PHASE)	HOLDING TORQUE (KG.CM)	MOTOR HEIGHT L(MM)	MOTOR WEIGHT (KG)
57BYGH350A-001	1.2	6	3.12	2.4	3.4	4.0	4.0	41	0.45
57BYGH350A-002	1.2	3	5.0	0.5	10	16	2.0	41	0.45
57BYGH350B-001	1.2	3	2.52	5.6	0.45	1.1	9.0	56	0.69
57BYGH350B-002	1.2	6	5.28	2.4	2.2	2	7.0	56	0.75
57BYGH350C-001-09	1.2	3	2.6	5.2	0.5	1.4	12	76	1.05
57BYGH350C-005-01	1.2	3	9.0	1.0	9.0	21	9	76	1.10

*Products can be customized by special request.

*Products can match gearbox 42,52,57,63mm

Wiring Diagram

Mechanical Dimension

GEARBOX Electrical Specification:

Out diameter 42mm Powder metallurgy

Housing material	Bearing at output	Radial load(10mm from flange)N	Shaft axial load(N)	Shaft press-fit force max(N)	Radial play of shaft(mm)	Thrust play of shaft(mm)	Backlash at no-load (°)
Powder metallurgy	sleeve bearing	≤120	≤80	≤500	≤0.03	≤0.1	≤1.5

Reduction ratio	Rated tolerance torque (Nm)	Max momentary tolerance torque (Nm)	Efficiency%	Length L (mm)	Weight(g)	Number of gear trains
1/4	1.0	3.0	81%	32.5	170	1
1/6
1/15	4.0	12	72%	46.3	207	2
1/18
1/25
1/36
1/54	8.0	25	65%	60.1	267	3
1/65
1/90
1/112
1/155
1/216	10	30	65%	60.1	267

Mechanical Dimension

Out diameter 52mm Zinc alloy

Housing material	Bearing at output	Radial load(10mm from flange)N	Shaft axial load(N)	Shaft press-fit force max(N)	Radial play of shaft(mm)	Thrust play of shaft(mm)	Backlash at no-load (°)
Zinc alloy	sleeve bearings	≤450	≤200	≤1000	≤0.03	≤0.1	≤1.5

Reduction ratio	Rated tolerance torque (Nm)	Max momentary tolerance torque (Nm)	Efficiency%	Length (mm)	Weight(g)	Number of gear trains
1/13	2.0	6.0	81%	52.9	345	1

Mechanical Dimension

Out diameter 56mm Powder metallurgy

Housing material	Bearing at output	Radial load(10mm from flange)N	Shaft axial load(N)	Shaft press-fit force max(N)	Radial play of shaft(mm)	Thrust play of shaft(mm)	Backlash at no-load (°)
Powder metallurgy	sleeve bearings	≤450	≤200	≤1000	≤0.03	≤0.1	≤1.5

Reduction ratio	Rated tolerance torque (Nm)	Max momentary tolerance torque (Nm)	Efficiency%	Length L (mm)	Weight(g)	Number of gear trains
1/4	2.0	6.0	81%	41.3	491	1
1/6
1/15	8.0	25	72%	59.6	700	2
1/18
1/26
1/47	16	50	72%	59.6	700	2
1/66

Mechanical Dimension

Out diameter 56mm Engineering plastics

Housing material	Bearing at output	Radial load(10mm from flange)N	Shaft axial load(N)	Shaft press-fit force max(N)	Radial play of shaft(mm)	Thrust play of shaft(mm)	Backlash at no-load (°)
Engineering plastics	sleeve bearing	≤450	≤200	≤1000	≤0.03	≤0.1	≤1.5

Reduction ratio	Rated tolerance torque (Nm)	Max momentary tolerance torque (Nm)	Efficiency%	Length L (mm)	Weight(g)	Number of gear trains
1/15	8.0	25	72%	61.6	450	2
1/18
1/26
1/47	16	50
1/66

Mechanical Dimension

Out diameter 56 mm Zinc alloy

Housing material	Bearing at output	Radial load(10mm from flange)N	Shaft axial load(N)	Shaft press-fit force max(N)	Radial play of shaft(mm)	Thrust play of shaft(mm)	Backlash at no-load (°)
Zinc alloy	sleeve bearings	≤450	≤200	≤1000	≤0.03	≤0.1	≤1.5

Reduction ratio	Rated tolerance torque (Nm)	Max momentary tolerance torque (Nm)	Efficiency%	Length L (mm)	Weight(g)	Number of gear trains
1/4	2.0	6	81%	43.3	350	1
1/6
1/13				52.7	400

Mechanical Dimension

Out diameter 63mm Zinc alloy

Housing material	Bearing at output	Radial load(10mm from flange)N	Shaft axial load(N)	Shaft press-fit force max(N)	Radial play of shaft(mm)	Thrust play of shaft(mm)	Backlash at no-load (°)
Zinc alloy	sleeve bearings	≤450	≤200	≤1000	≤0.03	≤0.1	≤1.5

Reduction ratio

Rated tolerance torque (Nm)

Max momentary tolerance torque (Nm)

Efficiency%

Length

L(mm)

Weight(g)

Number of gear trains

1/8

3.0

8.0

81%

75.5

400

Mechanical Dimension

How Does a Planetary Gearbox Work?

The alignment of the gears can be compared to our solar system where the planets revolve around the sun, hence the name “Planetary Gearbox”.

In the middle of the planetary gearbox, there is a “sun” gear –also known as a central gear. This is often the input gear. Around the outside, there are 2 or more “planet” gears – or outer gears. Surrounding the planet gears there is a ring gear that holds the formation together. The planet gears are connected by a carrier which in turn is connected to the output shaft.
