High Power Dc310v Brushless Permanent Magnet Motor 440W 1.4 Nm 86BLF01F 003

Ask Lasest Price
Brand Name :	HeTai
Model Number :	86BLF01F-003
Certification :	CE ROHS ISO
Price :	USD
Payment Terms :	L/C, D/P, T/T, Western Union, MoneyGram
Supply Ability :	10000 PCS/MONTH
Delivery Time :	25 DAYS

Add to Cart

Product Details
Company Profile

High Power Dc310v Brushless Permanent Magnet Motor 440W 1.4 Nm 86BLF01F 003

86BLF01F-003 440W 3000RPM 1.4NM stable performance Three-phase brushless DC motor

-Resistance 5.7 OHMS

-No-load current 0.4A

-No-load speed 3800RPM

-Max Radial Force 220N (10mm from front flange)

-Max Axial Force 60N

Electrical Specification:

Specification	Unit	86BLF01F-003
Number Of Phases	Phase	3
Number Of Poles	Poles	8
Rated Voltage	VDC	310
Rated Speed	Rpm	3000
Rated Torque	N.m	1.4
Rated Power	W	440
Peak Torque	N.m	4.2
Torque Constant	N.m/A	0.78
Back EMF constant	V/kRPM	81.6
Body Length	mm	97
Weight	Kg	2.99

*Products can be customized by special request.

Wiring Diagram

FUNCTION	COLOR
+5V	WHITE	UL1007 26AWG
HALL A	RED
HALLB	YELLOW
HALLC	BLUE
GND	BLACK
PHASE A	RED	UL1015 18AWG
PHASE B	YELLOW
PHASE C	BLUE

Mechanical Dimension

Based on all this advantages, our company specializes in producing hybrid stepping motors, DC brushless motors, servo motors, gearbox motors and so on. The products are applied in robots, packing machinery, textile machinery, medical instruments, printing machinery, intelligent logistics equipment... Hetai also sends its products to USA, Europe, Southeast Asia and all-around China.

1. Are you a factory?

Yes, we are a factory. Our brand name Hetai is a well-known micro motor manufacturer for more than 20 years in

China. Main products including hybrid stepper motor, brushless DC motor, servo motor, and planetary gearbox.

2. Can I test the sample?

Yes, samples and freight are charged.

3. Can I get a Customized product?

Sure, all the products can be customized based on special requests.

4. How do you ship the goods?

We normally ship goods by express(DHL/UPS/FEDEX/TNT), by sea and by air, also accept freight forwarder.

5. What are the payment terms?

T/T(bank transfer), Paypal(0.5% paypal charges), ALIBABA assurance order accept

6. Is this your final price? May I have the discount?

Our price is the factory price. If you have a large quantity, we can negotiate about the discount.

7. What is the Warranty for your products?

Our warranty is for one year. If any quality problems occurred on our side during this period, we will take on the shipping cost and replacement. please note damage caused by improper use of the product is not covered by the warranty.
