42BYGH 2 phase 1.8 degree Nema 17 Integrated Stepper Motor

The ADVANTAGE of Step motor:

Advantages of step motors are low cost, high reliability, high torque at low speeds, and simple, rugged construction that operates in almost any environment. The main disadvantage in using a stepper motor is the resonance effect often exhibited at low speeds and decreasing torque with increasing speed.

42BYGH series motors are all able to add the integrated driver.

Motor Electrical Specification:

***Note: The products can be customized by your request. Please contact us for more details.

Driver Manual

HTD421 2 phase Parallel interface driver

Product Feature

Miniature design, convenient installation, can be integrated with 42 stepper motors

- Heat-dissipated cast aluminum enclosed housing

- Automatic half current when stopped running

- Parallel interface high-speed photoelectric isolation, compatible with 3.3-5V and 12-24V logic levels 2A continuously adjustable

- Microstep 1/2/4/8/16/32 optional subdivision

Product Parameter

The driver has the same hole position and size as the 42 stepper motor.

Product Advantage

The advantages of integrated motors include ease of layout, reduced wiring complexity, faster system setup and construction, and motor driver compatibility. In addition, an integrated unit with an integrated control system is also provided.

The benefits of the integrated motor and drive units include ease of implementation, reduced wiring complexity, faster setup and construction of a system, and guaranteed motor-drive compatibility. Additionally, integrated units that incorporate systems on a chip (SoC) are also available.

Changzhou Hetai Motors

Hetai is located in Changzhou, Jiangsu province. Our workshop area is over 15,000㎡. Since Hetai was founded in 1999, the specialization and scale of production have ensured to manufacture of five million motors every year.

Factory Scale Of Hetai

Since the reorganization in 1998, it has formed a certain scale of production and sales, with an annual production of more than 3 million motors.

Changzhou Hetai Motors is an experienced motor manufacturer. For more than 20 years, Hetai dedicates to providing professional electrical integration design and automation strategies for customers. We have variable manufacturing equipment, such as an assembly line, Automatic cylindrical grinder, and CNC machining centers as well.

Products Range Of Hetai

Stepper Motor, Planetary Gearbox& Gearbox Motor, Brushless DC Motor, Servo Motor.

Changzhou Hetai Electric Appliance Co., Ltd. is a micro-motor manufacturing enterprise with strong technical strength. Specializing in the production of various stepper motors, stepper motor drivers, brushless DC motors, etc., with an annual output of 3 million units! Products are mainly used in printers, ticket printing machines, engraving machines, medical instruments, stage lighting, the textile industry, and other industries of automation equipment and instruments.

Market Range of Hetai

Hetai also sends its products to the USA, Europe, Southeast Asia, and all-around China.

Certificate Of Hetai

When it comes to the quality aspect, Hetai was qualified by ISO Certificate, CE, Reach and  Rohs. The product quality has also been recognized by many customers. Hetai is also proud of its research and development strength. With the support of a professional laboratory and experienced technicians, Hetai gained 13 Utility Patents and high-tech enterprise Awards as well as other awards during the years.

Overall, Hetai always puts customer needs a first place. Not only supplying a quality products, we believe to help customers make better product is the most important mission.
