    310V 20 Nm Servo Motor With Encoder 4kw IP65

    Ask Lasest Price
    Brand Name : Hetai
    Model Number : ES130 4KW
    Certification : CE ROHS ISO
    Price : USD
    Payment Terms : L/C, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 1000pcs/month
    Delivery Time : 28-31
    • Product Details
    • Company Profile

    310V 20 Nm Servo Motor With Encoder 4kw IP65

    ES130 series 4KW 310V High power 20Nm rated smooth running precise control with encoder servo motor


    Model ES 130 -310V (without brake)
    Rated PowerMax radial forceMax axial forceWeightShaft typeShaft diameterFeedback device
    4000W490N196N15kgKey shaftφ22Multi-turn absolute encoder 17 bit

    Electrical Specification:


    Product Name:

    Servo Motor

    Rated Power (W)

    4000

    Rated Speed (RPM)

    2000

    Voltage(VDC)

    310

    Rated Current(A)

    20

    Rated Torque (N.m)

    20

    Peak Torque(N.m)

    40max

    Back EMF Constant(V/Krpm)

    54


    Note: The products can be customized by your request. Please contact us for more details.

    Type

    130

    Power

    1KW

    1.5KW

    2KW

    4KW

    Encoder





    L
    (mm)


    A





    B





    L

    143.5

    157

    171

    226

    N

    Type130
    Power1KW1.5KW2KW4KW
    Encoder

    Weight
    (Kg)


    A
    B
    L56.097.211.4
    N

    servo motor application

    Robotics

    Camera Auto Focus

    Robotic Vehicle

    Solar Tracking System

    Antenna Positioning

    Woodworking/CNC

    Textiles

    ...
